9KG 33 – Cooker With oven

Industrials Stoves/Cookers

İNOKSAN 9KG 33 – Cooker With oven
Puan 4.4/5 Yorum 480
6.12.2024
4.2/ 5

Features

  • Width: 120 cm
  • Depth: 92 cm
  • Height: 92 cm
  • Pallet box dimensions: 1222x937x1006 mm
More Information

General features

Width 120 cm
Depth 92 cm
Height 92 cm
Pallet box dimensions 1222x937x1006 mm

Functional Features

Technicial Specifications

Gas Inlet R3/4"
Gas consumption 46010 Kcal/h
Total power 53,5 kW
Max Throttle Power 53,5 kW
Cooker Power 45 kW
Furnace power 8,5 kW
Burner (Rainer) Ø100 / Ø130 mm
Burner (Oven) 1 / 8,5 Ad/kW
Burner power 3*6 / 3*9 Ad/kW

Accessory

GENERAL FEATURES

  • Cooker
  • Perfect 900 line, 1.5 module, with cabinet
  • External surfaces of 18/8 Cr-Ni s/s satin finished sheet,
  • All of the sheets and which are not exposed are of aluminized sheet,
  • All of the  electric board and control devices including plates in conformity with the international standards,
  • It produces with cabinet as standart. Cabinet are manufactured from stainless stell. Cabinet doors are with plastic holder.
  • Separate operation of the plates at different positions by 4 step switches,
  • It is manufactured with cabinet as standart. Cabinet is manufactured from stainless stell. Cabinet doors are with plastic holder,
  • On cupboard (with or without doors) suitable for multi-pupose use or on cantilever for island type installations .
  • Adjustable feet of stainless stell pipe , carrier sheet is 2 mm aluminized sheet..
  • Inside of AISI 430 BA sheet and with 3 tray slides,
  • It has turbo cooking property,
  • AISI 430 BA bottom sheet specially designed for homogeneous heat distribution



TECHNICAL SPECIFICATION

Total Power

53,5

kW

Cooker Power

45

kW

Boiler (Cooker)

Ø100 / Ø130

mm

Boiler (Cooker)

3*6 / 3*9

Ad/kW

Oven Power

8,5

kW

Boiler (Oven)

1 / 8,5

Ad/kW

Consumption

46010

Kcal/h

Gas Inlet

R3/4

Inch

Palett+Box Measures

1222x937x1006

WxDxH



GAZLI KUZİNE KULLANIM KILAVUZU
GAZLI KUZİNE KULLANIM KILAVUZU
9KG 33 SPEC SHEET
9KG 33 SPEC SHEET
9KG 33 ÜRÜN TANITIM FÖYÜ
9KG 33 ÜRÜN TANITIM FÖYÜ

Request/Information Form

9KG 33 – Cooker With oven
